Product Parameters
Product Name:
Fast Resin UV Curable Resin
Net Weight:
1Kg/2.2lb
Gross Weight:
1.15Kg/2.5lb
Package Size:
98*98*225mm
Applicable Model:
LCD printer
Density:
1.10-1.20g/cm3 @25°С
Viscosity:
50-100cps @25℃
Tensile Strength:
32Mpa
Elongation at Break:
10.5%
Bending Strength:
45Mpa
Flexural Modulus:
1552Mpa
Notched Impact Strength:
60J/m
Heat deflection temperature:
45℃
Hardness after curing:
77D
↓High-speed mode(worked with HALOT MAGE PRO)↓
Printing exposure:
1.2s
Light-off delay:
1s
Motor speed:
50mm/s
Printing rise height:
8mm
Initial exposure:
30s
Bottom exposure layers:
4 layers
Buffer layer height:
5
Buffer layer motor speed:
20
Buffer light-off delay:
1s
Clear screen exposure time:
8s
↓Normal mode↓
Printing exposure:
1.2s
Light-off delay:
1s
Motor speed:
5mm/s
Printing rise height:
8mm
Initial exposure:
30s
Bottom exposure layers:
4 layers
